| Actions | Basic Information | Basic Dimensions | Mounting Dimensions | Shoulder Dimensions | Basic Load Ratings | Precision & Clearance | Weight & Speed | Brand Cross-Reference | Assembly Parameters | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PDF Download | Inquiry | Model | Series | Nominal Model | Inner Diameter d (mm) |
Outer Diameter D (mm) |
Height H/B (mm) |
H/B (mm) |
B1 (mm) |
dp (mm) |
Roller Pitch Circle Diameter Dpw (mm) |
T (mm) |
H2 (mm) |
S (mm) |
C (mm) |
C1 (mm) |
d1 (mm) |
D1 (mm) |
D2 (mm) |
dn (mm) |
dm (mm) |
d2 (mm) |
d3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
Chamfer rmin (mm) |
R Fillet Radius |
Inner Ring do (mm) |
Inner Ring ds (mm) |
Inner Ring Ts (mm) |
Inner Ring Mounting Hole Size Seal Back Side |
Inner Ring Mounting Hole Size 2 |
Inner Ring Mounting Dimensions |
Inner Ring Mounting Hole Center Diameter PCD₁ |
Inner Ring Mounting Hole Center Diameter dn (mm) |
Inner Ring Mounting Hole Center Diameter dL (mm) |
Inner Ring Mounting Hole Size 1 |
Inner Ring Mounting Hole Size Seal Front Side |
Inner Ring N | Inner Ring n-ΦN |
Inner Ring n-ΦQ3 |
Outer Ring Mounting Dimensions |
Outer Ring Mounting Hole Center Diameter PCD₂ |
Outer Ring Mounting Hole Center Diameter dm (mm) |
Outer Ring Mounting Hole Size 1 |
Outer Ring Mounting Hole Size 2 Seal Back Side |
Outer Ring W1 | Outer Ring n-ΦW1 |
Outer Ring n-ΦQ1 |
Outer Ring W2 | Outer Ring n-ΦW2 |
Outer Ring n-ΦQ2 |
Outer Ring dL (mm) |
Shoulder Dimensions ds (mm) |
Shoulder Dimensions Dh (mm) |
Radial Static Load Cor (N) |
Radial Dynamic Load Cr (N) |
Axial Static Load Coa (N) |
Axial Dynamic Load Ca (N) |
Dynamic Load Radial (kg) |
Dynamic Load Axial (kg) |
Limit Load Radial Static Load (N) |
Limit Load Radial Dynamic Load (N) |
Thrust (N) |
Moment Static Load (N·m) |
Moment Dynamic Load (N·m) |
Moment (N·m) |
Standard Radial Clearance |
Inner Ring Runout | Outer Ring Runout | Weight (g) |
Weight (KG) |
Limit Speed Grease Lubrication (r/min) |
Bearing Friction Torque (Nm) |
NTN | INA | KAYDON | Inner Ring Quantity | Outer Ring Quantity | Connecting Screw Quantity |
Lifting Hole G | Lifting Hole Quantity | Pitch t Quantity×t |
Screw Tightening Torque MA (Nm) |
Compatible Reducer Type |
| PDF Download | Inquiry | K02508C | Type C | — | 25 | 41 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 303 | 255 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.06 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K05008C | Type C | — | 50 | 66 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 556 | 350 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.08 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K06008C | Type C | — | 60 | 76 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 656 | 384 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.09 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K07008C | Type C | — | 70 | 86 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 758 | 417 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.1 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K08008C | Type C | — | 80 | 96 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 859 | 448 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.11 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K09008C | Type C | — | 90 | 106 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 959 | 478 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.13 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K10008C | Type C | — | 100 | 116 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1061 | 507 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.14 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K11008C | Type C | — | 110 | 126 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1162 | 534 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.15 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K12008C | Type C | — | 120 | 136 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1262 | 561 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.16 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K13008C | Type C | — | 130 | 146 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1364 | 588 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.18 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K14008C | Type C | — | 140 | 156 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1465 | 613 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.19 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K15008C | Type C | — | 150 | 166 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1565 | 638 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.2 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K16008C | Type C | — | 160 | 176 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1666 | 662 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.2 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K17008C | Type C | — | 170 | 186 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1767 | 686 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.2 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K18008C | Type C | — | 180 | 196 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1868 | 709 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.21 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K19008C | Type C | — | 190 | 206 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1944 | 725 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.21 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K20008C | Type C | — | 200 | 216 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2045 | 748 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.22 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K25008C | Type C | — | 250 | 266 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2550 | 853 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.28 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K30008C | Type C | — | 300 | 316 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 3055 | 949 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.35 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | K32008C | Type C | — | 320 | 336 | 8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 3257 | 985 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.39 | — | — | — | — | — | — | — | — | — | — | — | — | — |
