| Actions | Basic Information | Basic Dimensions | Mounting Dimensions | Shoulder Dimensions | Basic Load Ratings | Precision & Clearance | Weight & Speed | Brand Cross-Reference | Assembly Parameters | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PDF Download | Inquiry | Model | Series | Nominal Model | Inner Diameter d (mm) |
Outer Diameter D (mm) |
Height H/B (mm) |
H/B (mm) |
B1 (mm) |
dp (mm) |
Roller Pitch Circle Diameter Dpw (mm) |
T (mm) |
H2 (mm) |
S (mm) |
C (mm) |
C1 (mm) |
d1 (mm) |
D1 (mm) |
D2 (mm) |
dn (mm) |
dm (mm) |
d2 (mm) |
d3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
Chamfer rmin (mm) |
R Fillet Radius |
Inner Ring do (mm) |
Inner Ring ds (mm) |
Inner Ring Ts (mm) |
Inner Ring Mounting Hole Size Seal Back Side |
Inner Ring Mounting Hole Size 2 |
Inner Ring Mounting Dimensions |
Inner Ring Mounting Hole Center Diameter PCD₁ |
Inner Ring Mounting Hole Center Diameter dn (mm) |
Inner Ring Mounting Hole Center Diameter dL (mm) |
Inner Ring Mounting Hole Size 1 |
Inner Ring Mounting Hole Size Seal Front Side |
Inner Ring N | Inner Ring n-ΦN |
Inner Ring n-ΦQ3 |
Outer Ring Mounting Dimensions |
Outer Ring Mounting Hole Center Diameter PCD₂ |
Outer Ring Mounting Hole Center Diameter dm (mm) |
Outer Ring Mounting Hole Size 1 |
Outer Ring Mounting Hole Size 2 Seal Back Side |
Outer Ring W1 | Outer Ring n-ΦW1 |
Outer Ring n-ΦQ1 |
Outer Ring W2 | Outer Ring n-ΦW2 |
Outer Ring n-ΦQ2 |
Outer Ring dL (mm) |
Shoulder Dimensions ds (mm) |
Shoulder Dimensions Dh (mm) |
Radial Static Load Cor (N) |
Radial Dynamic Load Cr (N) |
Axial Static Load Coa (N) |
Axial Dynamic Load Ca (N) |
Dynamic Load Radial (kg) |
Dynamic Load Axial (kg) |
Limit Load Radial Static Load (N) |
Limit Load Radial Dynamic Load (N) |
Thrust (N) |
Moment Static Load (N·m) |
Moment Dynamic Load (N·m) |
Moment (N·m) |
Standard Radial Clearance |
Inner Ring Runout | Outer Ring Runout | Weight (g) |
Weight (KG) |
Limit Speed Grease Lubrication (r/min) |
Bearing Friction Torque (Nm) |
NTN | INA | KAYDON | Inner Ring Quantity | Outer Ring Quantity | Connecting Screw Quantity |
Lifting Hole G | Lifting Hole Quantity | Pitch t Quantity×t |
Screw Tightening Torque MA (Nm) |
Compatible Reducer Type |
| PDF Download | Inquiry | RAU/RA 5008 | — | — | 50 | 66 | 8 | — | — | — | 57 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 53.5 | 60.5 | 7.19 | 5.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.08 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 6008 | — | — | 60 | 76 | 8 | — | — | — | 67 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 63.5 | 70.5 | 8.68 | 5.68 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.09 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 7008 | — | — | 70 | 86 | 8 | — | — | — | 77 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 73.5 | 80.5 | 9.8 | 5.98 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.1 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 8008 | — | — | 80 | 96 | 8 | — | — | — | 87 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 83.5 | 90.5 | 11.3 | 6.37 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.11 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 9008 | — | — | 90 | 106 | 8 | — | — | — | 97 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 93.5 | 100.5 | 12.4 | 6.76 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.12 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 10008 | — | — | 100 | 116 | 8 | — | — | — | 107 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 103.5 | 110.5 | 13.9 | 7.15 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.14 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 11008 | — | — | 110 | 126 | 8 | — | — | — | 117 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 113.5 | 120.5 | 15 | 7.45 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.15 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 12008 | — | — | 120 | 136 | 8 | — | — | — | 127 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 123.5 | 130.5 | 16.5 | 7.84 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.17 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 13008 | — | — | 130 | 146 | 8 | — | — | — | 137 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 133.5 | 140.5 | 17.6 | 7.94 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.18 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 14008 | — | — | 140 | 156 | 8 | — | — | — | 147 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 143.5 | 150.5 | 19.1 | 8.33 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.19 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 15008 | — | — | 150 | 166 | 8 | — | — | — | 157 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 153.5 | 160.5 | 20.6 | 8.82 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.2 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 16013 | — | — | 160 | 186 | 13 | — | — | — | 172 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 165 | 179 | 44.9 | 23.3 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.59 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 17013 | — | — | 170 | 196 | 13 | — | — | — | 182 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 175 | 189 | 46.5 | 23.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.64 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 18013 | — | — | 180 | 206 | 13 | — | — | — | 192 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 185 | 199 | 49.8 | 24.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.68 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 19013 | — | — | 190 | 216 | 13 | — | — | — | 202 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 195 | 209 | 51.5 | 24.9 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.69 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RAU/RA 20013 | — | — | 200 | 226 | 13 | — | — | — | 212 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 205 | 219 | 54.7 | 25.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.71 | — | — | — | — | — | — | — | — | — | — | — | — | — |
