| Actions | Basic Information | Basic Dimensions | Mounting Dimensions | Shoulder Dimensions | Basic Load Ratings | Precision & Clearance | Weight & Speed | Brand Cross-Reference | Assembly Parameters | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PDF Download | Inquiry | Model | Series | Nominal Model | Inner Diameter d (mm) |
Outer Diameter D (mm) |
Height H/B (mm) |
H/B (mm) |
B1 (mm) |
dp (mm) |
Roller Pitch Circle Diameter Dpw (mm) |
T (mm) |
H2 (mm) |
S (mm) |
C (mm) |
C1 (mm) |
d1 (mm) |
D1 (mm) |
D2 (mm) |
dn (mm) |
dm (mm) |
d2 (mm) |
d3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
Chamfer rmin (mm) |
R Fillet Radius |
Inner Ring do (mm) |
Inner Ring ds (mm) |
Inner Ring Ts (mm) |
Inner Ring Mounting Hole Size Seal Back Side |
Inner Ring Mounting Hole Size 2 |
Inner Ring Mounting Dimensions |
Inner Ring Mounting Hole Center Diameter PCD₁ |
Inner Ring Mounting Hole Center Diameter dn (mm) |
Inner Ring Mounting Hole Center Diameter dL (mm) |
Inner Ring Mounting Hole Size 1 |
Inner Ring Mounting Hole Size Seal Front Side |
Inner Ring N | Inner Ring n-ΦN |
Inner Ring n-ΦQ3 |
Outer Ring Mounting Dimensions |
Outer Ring Mounting Hole Center Diameter PCD₂ |
Outer Ring Mounting Hole Center Diameter dm (mm) |
Outer Ring Mounting Hole Size 1 |
Outer Ring Mounting Hole Size 2 Seal Back Side |
Outer Ring W1 | Outer Ring n-ΦW1 |
Outer Ring n-ΦQ1 |
Outer Ring W2 | Outer Ring n-ΦW2 |
Outer Ring n-ΦQ2 |
Outer Ring dL (mm) |
Shoulder Dimensions ds (mm) |
Shoulder Dimensions Dh (mm) |
Radial Static Load Cor (N) |
Radial Dynamic Load Cr (N) |
Axial Static Load Coa (N) |
Axial Dynamic Load Ca (N) |
Dynamic Load Radial (kg) |
Dynamic Load Axial (kg) |
Limit Load Radial Static Load (N) |
Limit Load Radial Dynamic Load (N) |
Thrust (N) |
Moment Static Load (N·m) |
Moment Dynamic Load (N·m) |
Moment (N·m) |
Standard Radial Clearance |
Inner Ring Runout | Outer Ring Runout | Weight (g) |
Weight (KG) |
Limit Speed Grease Lubrication (r/min) |
Bearing Friction Torque (Nm) |
NTN | INA | KAYDON | Inner Ring Quantity | Outer Ring Quantity | Connecting Screw Quantity |
Lifting Hole G | Lifting Hole Quantity | Pitch t Quantity×t |
Screw Tightening Torque MA (Nm) |
Compatible Reducer Type |
| PDF Download | Inquiry | BB3010 | — | — | 30 | 55 | 10 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 497 | 675 | — | — | — | — | — | 78 | 0.025-0.038 | 0.01 | 0.01 | — | 0.1 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB3510 | — | — | 35 | 60 | 10 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 513 | 709 | — | — | — | — | — | 90 | 0.03-0.043 | 0.01 | 0.01 | — | 0.11 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB4010 | — | — | 40 | 65 | 10 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 553 | 776 | — | — | — | — | — | 107 | 0.03-0.043 | 0.013 | 0.013 | — | 0.12 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB4510 | — | — | 45 | 70 | 10 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 591 | 839 | — | — | — | — | — | 125 | 0.03-0.043 | 0.013 | 0.013 | — | 0.13 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB5013 | — | — | 50 | 80 | 13 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 948 | 1321 | — | — | — | — | — | 227 | 0.03-0.056 | 0.013 | 0.013 | — | 0.24 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB6013 | — | — | 60 | 90 | 13 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1010 | 1436 | — | — | — | — | — | 279 | 0.03-0.056 | 0.013 | 0.013 | — | 0.3 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB7013 | — | — | 70 | 100 | 13 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1108 | 1601 | — | — | — | — | — | 346 | 0.03-0.056 | 0.015 | 0.015 | — | 0.31 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB8016 | — | — | 80 | 120 | 16 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1679 | 2417 | — | — | — | — | — | 618 | 0.03-0.056 | 0.015 | 0.015 | — | 0.62 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB9016 | — | — | 90 | 130 | 16 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1773 | 2584 | — | — | — | — | — | 718 | 0.041-0.066 | 0.015 | 0.015 | — | 0.73 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB10020 | — | — | 100 | 150 | 20 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2395 | 3480 | — | — | — | — | — | 1102 | 0.041-0.066 | 0.015 | 0.015 | — | 1.21 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB11015 | — | — | 110 | 145 | 15 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1390 | 2097 | — | — | — | — | — | 652 | 0.041-0.066 | 0.015 | 0.02 | — | 0.66 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB11020 | — | — | 110 | 160 | 20 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2524 | 3720 | — | — | — | — | — | 1300 | 0.041-0.066 | 0.015 | 0.02 | — | 1.36 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB12025 | — | — | 120 | 180 | 25 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 3981 | 5745 | — | — | — | — | — | 2197 | 0.05-0.08 | 0.02 | 0.02 | — | 2.13 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB13025 | — | — | 130 | 190 | 25 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 4098 | 5968 | — | — | — | — | — | 2412 | 0.05-0.08 | 0.025 | 0.025 | — | 2.27 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB14025 | — | — | 140 | 200 | 25 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 4359 | 6402 | — | — | — | — | — | 2726 | 0.05-0.08 | 0.025 | 0.025 | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB15013 | — | — | 150 | 180 | 13 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1590 | 2455 | — | — | — | — | — | 965 | 0.05-0.08 | 0.025 | 0.025 | — | 0.61 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB15025 | — | — | 150 | 210 | 25 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 4468 | 6614 | — | — | — | — | — | 2959 | 0.05-0.08 | 0.025 | 0.025 | — | 2.72 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB15030 | — | — | 150 | 230 | 30 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 6403 | 9325 | — | — | — | — | — | 4475 | 0.05-0.08 | 0.025 | 0.025 | — | 4.54 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB20025 | — | — | 200 | 260 | 25 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 5121 | 7820 | — | — | — | — | — | 4333 | 0.06-0.09 | 0.03 | 0.03 | — | 3.4 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | BB20030 | — | — | 200 | 280 | 30 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 7288 | 10980 | — | — | — | — | — | 6435 | 0.06-0.09 | 0.03 | 0.03 | — | 5.72 | — | — | — | — | — | — | — | — | — | — | — | — | — |
