| Actions | Basic Information | Basic Dimensions | Mounting Dimensions | Shoulder Dimensions | Basic Load Ratings | Precision & Clearance | Weight & Speed | Brand Cross-Reference | Assembly Parameters | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PDF Download | Inquiry | Model | Series | Nominal Model | Inner Diameter d (mm) |
Outer Diameter D (mm) |
Height H/B (mm) |
H/B (mm) |
B1 (mm) |
dp (mm) |
Roller Pitch Circle Diameter Dpw (mm) |
T (mm) |
H2 (mm) |
S (mm) |
C (mm) |
C1 (mm) |
d1 (mm) |
D1 (mm) |
D2 (mm) |
dn (mm) |
dm (mm) |
d2 (mm) |
d3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
Chamfer rmin (mm) |
R Fillet Radius |
Inner Ring do (mm) |
Inner Ring ds (mm) |
Inner Ring Ts (mm) |
Inner Ring Mounting Hole Size Seal Back Side |
Inner Ring Mounting Hole Size 2 |
Inner Ring Mounting Dimensions |
Inner Ring Mounting Hole Center Diameter PCD₁ |
Inner Ring Mounting Hole Center Diameter dn (mm) |
Inner Ring Mounting Hole Center Diameter dL (mm) |
Inner Ring Mounting Hole Size 1 |
Inner Ring Mounting Hole Size Seal Front Side |
Inner Ring N | Inner Ring n-ΦN |
Inner Ring n-ΦQ3 |
Outer Ring Mounting Dimensions |
Outer Ring Mounting Hole Center Diameter PCD₂ |
Outer Ring Mounting Hole Center Diameter dm (mm) |
Outer Ring Mounting Hole Size 1 |
Outer Ring Mounting Hole Size 2 Seal Back Side |
Outer Ring W1 | Outer Ring n-ΦW1 |
Outer Ring n-ΦQ1 |
Outer Ring W2 | Outer Ring n-ΦW2 |
Outer Ring n-ΦQ2 |
Outer Ring dL (mm) |
Shoulder Dimensions ds (mm) |
Shoulder Dimensions Dh (mm) |
Radial Static Load Cor (N) |
Radial Dynamic Load Cr (N) |
Axial Static Load Coa (N) |
Axial Dynamic Load Ca (N) |
Dynamic Load Radial (kg) |
Dynamic Load Axial (kg) |
Limit Load Radial Static Load (N) |
Limit Load Radial Dynamic Load (N) |
Thrust (N) |
Moment Static Load (N·m) |
Moment Dynamic Load (N·m) |
Moment (N·m) |
Standard Radial Clearance |
Inner Ring Runout | Outer Ring Runout | Weight (g) |
Weight (KG) |
Limit Speed Grease Lubrication (r/min) |
Bearing Friction Torque (Nm) |
NTN | INA | KAYDON | Inner Ring Quantity | Outer Ring Quantity | Connecting Screw Quantity |
Lifting Hole G | Lifting Hole Quantity | Pitch t Quantity×t |
Screw Tightening Torque MA (Nm) |
Compatible Reducer Type |
| PDF Download | Inquiry | SX011814 | — | — | 70 | 90 | 10 | — | — | 80 | — | — | — | 1.2 | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 79.5 | 80.5 | 30 | 12 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.3 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011818 | — | — | 90 | 115 | 13 | — | — | 102 | — | — | — | 1.2 | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 101.5 | 102.5 | 47 | 17 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.4 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011820 | — | — | 100 | 125 | 13 | — | — | 112 | — | — | — | 1.2 | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 111.5 | 112.5 | 52 | 18 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011824 | — | — | 120 | 150 | 16 | — | — | 135 | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 134.4 | 135.6 | 75 | 26 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.8 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011828 | — | — | 140 | 175 | 18 | — | — | 157 | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | 1.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 156.3 | 157.7 | 116 | 41 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.1 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011832 | — | — | 160 | 200 | 20 | — | — | 180 | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | 1.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 179.2 | 180.8 | 133 | 44 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.7 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011836 | — | — | 180 | 225 | 22 | — | — | 202 | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | 1.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 201.2 | 202.8 | 187 | 63 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2.3 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011840 | — | — | 200 | 250 | 24 | — | — | 225 | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 224.2 | 225.8 | 208 | 68 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 3.1 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011848 | — | — | 240 | 300 | 28 | — | — | 270 | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | 2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 269.2 | 270.8 | 300 | 95 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 5.3 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011860 | — | — | 300 | 380 | 38 | — | — | 340 | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | 2.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 339.2 | 340.8 | 504 | 156 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 12 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011868 | — | — | 340 | 420 | 38 | — | — | 380 | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | 2.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 379.2 | 380.8 | 563 | 167 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 13.5 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX011880 | — | — | 400 | 500 | 46 | — | — | 450 | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 449 | 451 | 833 | 244 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 24 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | SX0118/500 | — | — | 500 | 620 | 56 | — | — | 560 | — | — | — | 2.5 | — | — | — | — | — | — | — | — | — | — | — | — | 3 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 559 | 561 | 1244 | 355 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 44 | — | — | — | — | — | — | — | — | — | — | — | — | — |
HOMVIP specializes in the research and manufacturing of precision cross roller bearings, equal section thin-walled bearings, and harmonic reducer bearings. Our products are exported to more than 50 countries and regions worldwide.
