| Actions | Basic Information | Basic Dimensions | Mounting Dimensions | Shoulder Dimensions | Basic Load Ratings | Precision & Clearance | Weight & Speed | Brand Cross-Reference | Assembly Parameters | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PDF Download | Inquiry | Model | Series | Nominal Model | Inner Diameter d (mm) |
Outer Diameter D (mm) |
Height H/B (mm) |
H/B (mm) |
B1 (mm) |
dp (mm) |
Roller Pitch Circle Diameter Dpw (mm) |
T (mm) |
H2 (mm) |
S (mm) |
C (mm) |
C1 (mm) |
d1 (mm) |
D1 (mm) |
D2 (mm) |
dn (mm) |
dm (mm) |
d2 (mm) |
d3 (mm) |
L1 (mm) |
L2 (mm) |
L3 (mm) |
Chamfer rmin (mm) |
R Fillet Radius |
Inner Ring do (mm) |
Inner Ring ds (mm) |
Inner Ring Ts (mm) |
Inner Ring Mounting Hole Size Seal Back Side |
Inner Ring Mounting Hole Size 2 |
Inner Ring Mounting Dimensions |
Inner Ring Mounting Hole Center Diameter PCD₁ |
Inner Ring Mounting Hole Center Diameter dn (mm) |
Inner Ring Mounting Hole Center Diameter dL (mm) |
Inner Ring Mounting Hole Size 1 |
Inner Ring Mounting Hole Size Seal Front Side |
Inner Ring N | Inner Ring n-ΦN |
Inner Ring n-ΦQ3 |
Outer Ring Mounting Dimensions |
Outer Ring Mounting Hole Center Diameter PCD₂ |
Outer Ring Mounting Hole Center Diameter dm (mm) |
Outer Ring Mounting Hole Size 1 |
Outer Ring Mounting Hole Size 2 Seal Back Side |
Outer Ring W1 | Outer Ring n-ΦW1 |
Outer Ring n-ΦQ1 |
Outer Ring W2 | Outer Ring n-ΦW2 |
Outer Ring n-ΦQ2 |
Outer Ring dL (mm) |
Shoulder Dimensions ds (mm) |
Shoulder Dimensions Dh (mm) |
Radial Static Load Cor (N) |
Radial Dynamic Load Cr (N) |
Axial Static Load Coa (N) |
Axial Dynamic Load Ca (N) |
Dynamic Load Radial (kg) |
Dynamic Load Axial (kg) |
Limit Load Radial Static Load (N) |
Limit Load Radial Dynamic Load (N) |
Thrust (N) |
Moment Static Load (N·m) |
Moment Dynamic Load (N·m) |
Moment (N·m) |
Standard Radial Clearance |
Inner Ring Runout | Outer Ring Runout | Weight (g) |
Weight (KG) |
Limit Speed Grease Lubrication (r/min) |
Bearing Friction Torque (Nm) |
NTN | INA | KAYDON | Inner Ring Quantity | Outer Ring Quantity | Connecting Screw Quantity |
Lifting Hole G | Lifting Hole Quantity | Pitch t Quantity×t |
Screw Tightening Torque MA (Nm) |
Compatible Reducer Type |
| PDF Download | Inquiry | RB 2008 | — | — | 20 | 36 | 8 | — | — | — | 27 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 23.5 | 30.5 | 3.1 | 3.23 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.04 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 2508 | — | — | 25 | 41 | 8 | — | — | — | 32 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 28.5 | 35.5 | 3.83 | 3.63 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.05 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 3010 | — | — | 30 | 55 | 10 | — | — | — | 41.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 37 | 47 | 8.36 | 7.35 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.12 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 3510 | — | — | 35 | 60 | 10 | — | — | — | 46.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 41 | 51.5 | 9.12 | 7.64 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.13 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 4010 | — | — | 40 | 65 | 10 | — | — | — | 51.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 47.5 | 57.5 | 10.6 | 8.33 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.16 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 4510 | — | — | 45 | 70 | 10 | — | — | — | 56.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 51 | 61.5 | 11.3 | 8.62 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.17 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 5013 | — | — | 50 | 80 | 13 | — | — | — | 64 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 57.4 | 72 | 20.9 | 16.7 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.27 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 6013 | — | — | 60 | 90 | 13 | — | — | — | 74 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 68 | 82 | 24.3 | 18 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.3 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 7013 | — | — | 70 | 100 | 13 | — | — | — | 84 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 78 | 92 | 27.7 | 19.4 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.35 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 8016 | — | — | 80 | 120 | 16 | — | — | — | 98 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 91 | 111 | 42.1 | 30.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.7 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 9016 | — | — | 90 | 130 | 16 | — | — | — | 108 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 98 | 118 | 45.3 | 31.4 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.75 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 10016 | — | — | 100 | 140 | 16 | — | — | — | 119.3 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 109 | 129 | 48.6 | 31.7 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.83 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 10020 | — | — | 100 | 150 | 20 | — | — | — | 123 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 113 | 133 | 50.9 | 33.1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.45 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 11012 | — | — | 110 | 135 | 12 | — | — | — | 121.8 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 117 | 127 | 24.1 | 12.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.4 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 11015 | — | — | 110 | 145 | 15 | — | — | — | 126.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 122 | 136 | 41.5 | 23.7 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.75 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 11020 | — | — | 110 | 160 | 20 | — | — | — | 133 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 120 | 143 | 54 | 34 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.56 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 12016 | — | — | 120 | 150 | 16 | — | — | — | 134.2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 127 | 141 | 43.2 | 24.2 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.72 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 12025 | — | — | 120 | 180 | 25 | — | — | — | 148.7 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 133 | 164 | 100 | 66.9 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2.62 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 13015 | — | — | 130 | 160 | 15 | — | — | — | 144.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.6 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 137 | 152 | 46.7 | 25 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 0.72 | — | — | — | — | — | — | — | — | — | — | — | — | — |
| PDF Download | Inquiry | RB 13025 | — | — | 130 | 190 | 25 | — | — | — | 158 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 1.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 143 | 174 | 107 | 69.5 | — | — | — | — | — | — | — | — | — | — | — | — | — | — | 2.82 | — | — | — | — | — | — | — | — | — | — | — | — | — |
